1 Specifications
1.1 Output: Continuous current 18A, short time current 22A (less than 10 seconds);
1.2 Power Input :2-4 cells lithium battery or 5-12 NiMH / Ni-Cd battery pack;
1.3BEC output: 2A (linear regulator mode-linear mode);
1.4 maximum speed: 2-pole motor 210000 rev / minute, 6-pole motor 70000 rev / min, 12 poles, 35,000 rpm / min;
1.5 Dimensions: 45mm (length) * 24mm (width) * 11mm (H);
1.6 Weight: 19g (with heat sink);
1.7 Attachment: Gold-plated motor connectors and heat shrink tubing (optional);
2 Features
2.1 Safety function: when the power is turned on, regardless of the throttle stick in any position does not immediately start the motor, to avoid personal injury;
2.2 Throttle Calibration function: to adapt to the differences of the different Throttle range and improve throttle response linearity;
